HTBRV-250 G Electric Universal Hardness Tester
KASON HTBRV-250G Electric Universal hardness tester is a multi-purpose and multi-functional hardness tester that can perform Brinell, Rockwell and Vickers hardness tests and seven-level test force, which can meet the requirements of various hardness tests of users. It is a high-precision, high-stability hardness tester with improved mechanical structure and improved stability
Mainly used:
Determination of Brinell, Vickers, Rockwell hardness of ferrous metals, non-ferrous metals and hard alloys.
Wide range of applications, can be widely used to determine:
a. Brinell hardness of castings, annealed steel, normalized steel, non-ferrous metals and soft alloys;
b. Rockwell hardness of heat-treated materials such as quenching, quenching and tempering;
c. Vickers hardness of nitriding layer, ceramics, thin plate, metal sheet, electroplating layer and tiny parts.
Features:
The body of the product is formed in one step by a casting process and has undergone a long-term aging treatment. Compared with the panelization process, the deformation is extremely small in long-term use and can effectively adapt to various harsh environments;
Car paint, with high-quality paint and strong scratch resistance, can remain bright and new after years of use;
It is ready to use after power on, no weights need to be installed;
Equipped with hardness testing software, the test is convenient and intuitive;
The test force is applied by electronic closed-loop control and controlled by force sensor, which fully realizes the automatic operation of applying, maintaining and removing the test force;
The hardness values of each scale can be converted to each other;
|
Rockwell scale |
Initial test force |
3kgf (29.42N), 10kg (98.07N) |
|
Total test force |
15kgf (147.1N), 30kgf (294.2N), 45kgf (441.3N), 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N) |
|
|
Ruler |
HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRP, HRR, HRS, HRV, HR15N, HR30N, HR 45N, HR15T, HR30T, HR45T, HR15X, HR30X, HR45X, HR15Y, HR30Y, HR45Y, HR15W, HR30W, HR45W |
|
|
Brinell scale |
Test force |
5, 6.25, 10, 15.625, 30, 31.25, 62.5, 100, 125, 187.5, 250Kgf |
|
Ruler |
HBW1/5, HBW2.5/6.25, HBW1/10, HBW2.5/15.625, HBW1/30, HBW2.5/31.25, HBW2.5/62.5, HBW5/62.5, HBW10/100, HBW5/125, HBW2.5/187.5, HBW5/250 |
|
|
Vickers scale |
Test force |
5, 10, 20, 30, 40, 50, 60, 80, 100, 120Kgf |
|
Ruler |
HV5, HV10, HV20, HV30, HV40, HV50, HV60, HV80, HV100, HV120 |
|
|
Hardness tester host |
Display Mode |
External computer display |
|
Delay control |
0～60 seconds adjustable |
|
|
Distance from the center of the pressure head to the machine body |
170mm |
|
|
Maximum sample height |
110mm |
|
|
Turret station |
7-station turret |
|
|
Objective magnification |
2.5X,5X,10X,20X |
|
|
Press head station |
Rockwell indenter station, Brinell indenter station, Vickers indenter station |
|
|
Supply voltage |
AC220V±5%, 50～60Hz |
KASON is established in 2003,owns more than 8000 square meters factory.has a professional sales teams, modem enter prise technology center,scientific and technological research and development team. Our main products are Hydraulic Universal Test Machine, Electronic Universal Test Machine, Compression Testing Machine, Spring Testing Machine,Impact Testing Machine, Torsion Testing Machine, , Hardness Tester, Testing Machine Accessories.Machines passed the European CE authentication,American FDA certificate and and ISO 9001. Products sold to USA, Canada, Australia, Europe, Africa etc,more than 130 countries and supply OEM service for many customers.
Warranty:
1.1 year warranty for machine host.
2.English manual and Video CD for machine using and maintenance.We offer free training in our factory, welcome to visit and learn more about our machines.
3.Free accessories :Software ,manual, book, cd videos, USB control.
After-sales service:
Training to install (3 options):
1.Before delivery , we will provide relevant installation and operation videos, In the same time instructions and remote software will be installed on the computer. If online training is required, our engineers will get in touch with you at any time.
2.We have local cooperative agents who can provide training and also provide calibration services, but they will charge a certain fee accordingly.
3. We also provide overseas training and debugging services. We dispatch engineers from China. You are responsible for food, accommodation, and airfare. Our engineer training fee is 200 USD/day.
