Touch Screen Micro Vickers Hardness Testing Machineis mainly used for micro Vickers hardness measurement of various metals and some non-metallic materials. ), non-ferrous metals, heat post-treated parts, various tiny and thin parts, glass, ceramics, agate, gemstones, etc. for hardness determination, and also suitable for carbonization, effective depth of quenching and hardening layer, coating, surface coating and welding Heat-affected parts of parts. It can also be used to observe the internal metallographic structure of various metal parts and to collect, display and output images. It is especially suitable for measuring the hardness gradient distribution curve of the workpiece and measuring the surface hardness of the gear after heat treatment, and the depth of the effective hardened layer.
|
Model |
7HTMV-1000T |
|
Display model |
7-inch touch screen display |
|
Hardness values |
Direct display |
|
Exchange scales |
HRA、HRB、HRC、HRD、HRF、HV、HK、HBW、HR15N、HR30N、 HR45N、HR15T、HR30T、HR45T |
|
Test force |
10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、200gf (1.96N)、 300gf (2.94N)、500gf(4.9N)、1kgf (9.8N) |
|
Turret type |
Manual |
|
Loading and unloading mode |
Automatic |
|
Micrometer eyepiece multiple |
10X |
|
Measurement resolution |
0.25µm (drum reading) |
|
Objective magnification |
10X 40X |
|
Total magnification |
100X（objective）400X(measurement) |
|
Measurement range |
150µm |
|
Light source |
Halogen lamp (brightness adjustable) |
|
Hardness conversation |
Brinell, rockwell, surface rockwell |
|
Max. height of sample |
110mm |
|
Depth at center line |
110mm |
|
XY test table size |
100X100mm Max. movement：25*25mm |
1. 19 years experience.
2. Perfect workmanship. Always committed to research and development.
3. Ensure the products meet the quality standards.
4. Ensure the goods will be delivered on time.
5. We will reply you within 24 hours.
6. Provide warm and friendly service and after-sale service.
7. Guaranteed the good quality and best service, as you buy from local supplier.
8. Assorted designs, colors, styles, patterns and sizes are available.
9. Customized specifications are welcome.
KASON is established in 2003,owns more than 8000 square meters factory.has a professional sales teams, modem enter prise technology center,scientific and technological research and development team. Machines passed the European CE authentication,American FDA certificate and and ISO 9001. Products sold to USA, Canada, Australia, Europe, Africa etc,more than 130 countries and supply OEM service for many customers.
Q: What's the delivery time?
A: Within 3 to 5 working days for delivery
Q: What's the payment terms?
A: T/T 30% deposit 70% after machine completed
Q: Are you factory or trading company?
A: We're factory, and can do exporting ourselves and trading others if you want
Warranty:
1.1 year warranty for machine host.
2.English manual and Video CD for machine using and maintenance.We offer free training in our factory, welcome to visit and learn more about our machines.
3.Free accessories :Software ,manual, book, cd videos, USB control.
After-sales service:
Training to install (3 options):
A. We will supply the machine with training video and user's manual in English for installing, operation, maintenance and trouble-shooting, and shall give technical guide by e-mail, fax, telephone/MSN/ICQ and so on, when you meet some problems of installation, using or adjusting.
B. You can come to our factory for training. We will offer professional guide. Direct and effective face-to-face training.all sorts of tools and testing facility.
